Front and Rear Washer Motor
- With the washer motor connected to the reservoir tank, fill the reservoir tank with water.NOTE: Before filling the reservoir tank with water, check the filter for foreign material or contamination. If necessary, clean the filter.
- Connect positive (-) battery cables to terminal 1 and negative (+) battery cables to terminal 2 respectively.
- Check that the motor operates normally and the washer motor runs and water sprays from the front nozzles.
- If they are abnormal, replace the washer motor.
| No | Description |
|---|---|
| 1 | Ground |
| 2 | Windshield washer (+) |
| 3 | Rear washer (+) |
