Passenger side Foot Lamp

  1. Disconnect the negative (-) battery terminal.
  2. Remove the crash pad under cover.

    (Refer to Body - "CRASH PAD UNDER COVER ")

  3. Remove the foot lamp (A) after disconnecting lamp connector.
G16856230Courtesy of HYUNDAI MOTOR AMERICA
