Auxiliary Fluid Pump and Hybrid Seals - Hybrid Models
WARNING: This page is about a different car, the 2024 Chevrolet Equinox. However, it is still accessible from the selected car via links, so may be relevant.
| Callout | Component Name |
|---|---|
| 352 | A/Trans Auxiliary Fluid Pump Outlet Pipe Seal Assembly |
| 361 | A/Trans Auxiliary Fluid Pump Gasket |
| 362 | A/Trans Auxiliary Fluid Pump Seal |
| 363 | A/Trans Auxiliary Fluid Pump Cover Seal |
| 367 | A/Trans Auxiliary Fluid Pump Motor Cover Seal - O-ring |
| 371 | A/Trans Auxiliary Fluid Inlet Pump Seal |
