Installation Procedure

  1. GM4562241Courtesy of GENERAL MOTORS COMPANY

    Connect the electrical connector.

  2. Instrument Panel Knee Bolster (1) - Install
  3. GM4562240Courtesy of GENERAL MOTORS COMPANY

    Hood Primary Latch Release Cable Handle (2) - Install

    4. CAUTION:

    Refer to Fastener Caution .

  4. Instrument Panel Knee Bolster Bolt (1) - Install and tighten [3x] 2.5 N.m (22 lb in)
