Installation Procedure

WARNING: This page is about a different variant/trim than selected.

Courtesy of GENERAL MOTORS COMPANY

Engine Oil Level Indicator Switch O-Ring Seal (1) - Install NEW
Engine Oil Level Indicator Switch (2) - Install

CAUTION:

Refer to Fastener Caution .

Engine Oil Level Indicator Switch Bolt (3) - Install [2x] 10 N.m (89 lb in)
Engine Oil Level Switch Clip (4) - Install
Courtesy of GENERAL MOTORS COMPANY

Oil Pan (6) - Install - Oil Pan Replacement (AWD) , or Oil Pan Replacement (FWD)
