Installation Procedure

WARNING: This page is about a different car, the 2020 GMC Terrain and 2020 Chevrolet Equinox. However, it is still accessible from the selected car via links, so may be relevant.
  1. GM4528730Courtesy of GENERAL MOTORS COMPANY

    Install the auxiliary fluid accumulator (2) to the transmission. Auxiliary Fluid Accumulator Installation

  2. Install the radiator surge tank. Radiator Surge Tank Replacement (LYX without KL9) , or Radiator Surge Tank Replacement (LTG LYX with KL9)
