G19 Rear Window Washer Pump
 Courtesy of GENERAL MOTORS COMPANY
|
Connector Part Information
- Harness Type: Forward Lamp Harness
- OEM Connector: 13583821
- Service Connector: Not Available
- Description: 2 -Way F 2.8 MCP Series, Sealed (BU)
|
Terminal Part Information
| Terminal Type ID |
Terminated Lead |
Diagnostic Test Probe |
Terminal Removal Tool |
| I |
Not required |
J-35616-14 (GN) |
No Tool Required |
| Pin |
Size |
Color |
Circuit |
Function |
Terminal Type ID |
Option |
| 1 |
0.5 |
BU / VT |
392 |
Rear Window Washer Pump Control |
I |
- |
| 2 |
0.5 |
BK |
1150 |
Ground |
I |
- |
