Drive And Driven Sprocket, Drive Link, And Park Pawl Installation

WARNING: This page is about a different variant/trim than selected.

Fig 1: Exploded View Of Drive And Driven Sprocket, Drive Link, And Park Pawl Installation Components

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
1	Front Differential Carrier Baffle
2	Front Differential Carrier Baffle Bolt M6 x 16 (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 12 N.m (106 lb in)
3	Drive Link Lube Scoop Seal
4	Drive Link Lube Fluid Seal
5	Drive Link Lube Scoop
6	Driven Sprocket Bearing Assembly
7	Drive Sprocket Bearing Assembly
8	Driven Sprocket Assembly, Drive Sprocket Assembly and Drive Link NOTE: Install the drive link with the colored links and/or part number facing up. The drive link, drive, and driven sprocket assemblies must be installed at the same time. The ball bearing should spin freely and smoothly. The driven sprocket ball bearing inner race has a slight interference fit with the case. Tap gently with the palm of a hand or a soft tip hammer to install.
9	Park Pawl
10	Park Pawl Spring
11	Park Pawl Shaft NOTE: Check to ensure that the park pawl operates freely and is not binding.
