Engine Coolant Thermostat Housing Installation
WARNING: This page is about a different car, the 2017 GMC Acadia. However, it is still accessible from the selected car via links, so may be relevant.
| Callout | Component Name |
|---|---|
| 1 | Engine Coolant Temperature Sensor
CAUTION:
Refer to Fastener Caution . Tighten 9 N.m (80 lb in) |
| 2 | Engine Coolant Temperature Sensor Wire |
| 3 | Engine Coolant Thermostat Gasket
NOTE:
Install a NEW gasket. |
| 4 | Engine Coolant Thermostat Housing |
| 5 | Engine Coolant Thermostat Housing Bolt Tighten 10 N.m (89 lb in) |
