Sunroof Window Replacement - Front

WARNING: This page is about a different car, the 2017 GMC Acadia. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Sunroof Window - Front

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
1	Sunroof Window Screw (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 6 N.m (53 lb in)
2	Sunroof Window Procedure Open the sunroof window to the access the screws. Sunroof Window Height and Opening Fit Adjustment

Callout

Component Name

Sunroof Window Screw (Qty: 4)

CAUTION:

Refer to Fastener Caution .

Tighten
6 N.m (53 lb in)

Sunroof Window

Procedure

Open the sunroof window to the access the screws.
Sunroof Window Height and Opening Fit Adjustment
