Power, Ground, Serial Data and Front Controls

WARNING: This page is about a different car, the 2017 GMC Acadia. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Power, Ground, Serial Data and Front Controls
GM4372987Courtesy of GENERAL MOTORS COMPANY
