Special Tools
WARNING: This page is about a different car, the 2017 Cadillac ATS. However, it is still accessible from the selected car via links, so may be relevant.
| Illustration | Tool Number/Description |
|---|---|
| DT 35944-200A Cooler Flushing Adapter |
|
| DT 45096 Transmission Oil Cooling System Flush and Flow Test Tool |
|
| DT 45096-21 Cooler Flushing Adapter |
|
| DT 47678 Transmission Holding Flange |
|
| DT 47678-10 Transmission Holding Flange Adapter |
|
| DT 48074 Input and Output Shaft Seal Installer |
|
| DT 48802 Bearing Installer |
|
| DT 49139 Hub Remover Tool |
|
| DT 49216 Bushing Remover |
|
| DT-51075 Puller Adapter Set |
|
| DT-51076 Bearing and Gear Installer |
|
| DT-51077 Shift Shaft Seal Installer |
|
| J 3289-20 Holding Fixture |
|
| J-33785 Pinion Bearing Installer |
|
| J-35664 Pinion Shaft Bearing Installer |
|
| J 6125-1B Slide Hammer with Adapter |
|
| J 8001 Dial Indicator Set |
|
| J 8092 Universal Driver Handle |
|
| J 8433 Universal Bridge Puller |
|
| J 08614-A Pinion Flange Holder and Remover |
|
| J 21426 Extension Housing Seal Installer |
|
| DT-22888-D J-22888-D Right Differential Side Bearing Puller |
|
| J 22888-20A Universal Two Jaw Puller |
|
| J 22910-01 Split Plate |
|
| J 22912-B Rear Pinion and Axle Bearing Remover |
|
| J 23129 Universal Seal Remover |
|
| J 23907 Slide Hammer |
|
| J-23907-1 Slide Hammer with Bearing Adapter |
|
| J-24433 Pinion Cone and Side Bearing Installer |
|
| DT-25234 J-25234 Gear and Bearing Installer |
|
| J 26941 Bearing Race Remover |
|
| J 28537-17 Bearing Race Installer |
|
| J 29369-2 Bushing and Bearing Remover - 2-3 in |
|
| J 29873 Injector Nozzle Socket 30 mm |
|
| J 35616 GM Terminal Test Kit |
|
| J 36017 Valve Seal Remover |
|
| J 36183 Press Tube |
|
| J 36184 Press Tube Adapter |
|
| J 36190 Universal Driver Handle |
|
| J 36513 Split Plate |
|
| J 36850 Transjel® Lubricant |
|
| DT-37212 J-37212 Front Output Shaft Seal Installer |
|
| J 38205-1 Press Tube |
|
| J 39371 1st/2nd Synchronizer Installer |
|
| J 39431 5th/6th Driven Gear Puller |
|
| J 39431-3 5th Gear Puller Adapter Bolts |
|
| J 39433 Input Shaft Seal Installer |
|
| J 39435 Bearing Race Installer |
|
| J 39437 Bushing Installer |
|
| J 39438 Bearing Installer |
|
| J 39439-1 Shift Rail Bushing Remover/Installer |
|
| J 39439-2 Bushing Remover |
|
| J 39439-3 Bushing Installer |
|
| J 39439-4 Bushing Installer |
|
| J 39441 5th/6th Driven Gear Installer |
|
| J 39441-10 5th Gear Installer Adapter |
|
| J 39441-20 5th Gear Installer Adapter |
|
| J 39442 Press Adapter |
|
| J 39443 Split Plate |
|
| J 39444-1 Countershaft End Play Rod |
|
| J 39444-2 Countershaft Extension End Play Rod |
|
| J 39473 Mainshaft Bearing Installer/Adapter |
|
| J 39511 Split Plate |
|
| J 39546 Bearing Race Installer |
|
| J 39547 Press Adapter |
|
| J 39594 Bearing Race Remover |
|
| J 39790 Mainshaft Bearing Race Remover |
|
| J 41099 Skip Shift Sensor Remover/Installer |
|
| J-41618 Crankshaft Balancer Remover |
|
| J 44384 Shift Fork Bearing Installer |
|
| J 44735 Installation Tube |
|
| J-44907 Bearing Installer |
|
| DT-44908 J-44908 Bearing Race Installer |
|
| J 44765 Seal Installer |
|
| J 44873 Shoulder Bolts |
|
| J 45012 Holding Fixture |
|
| J 45019 Flange and Pinion Gauge Remover |
|
| J 45124 Removal Bridge |
|
| J 45124-9 Puller Leg |
|
| J-45342-1 Press Tube |
|
| DT-46627-A J-46627-A Seal Installer |
|
| DT-47724 Output Shaft Bearing Cup Installer |
