Turbocharger Oil Feed Pipe Removal
WARNING: This page is about a different car, the 2017 Cadillac ATS. However, it is still accessible from the selected car via links, so may be relevant.
Turbocharger Oil Feed Pipe Removal
| Callout | Component Name |
|---|---|
| 1 | Turbocharger Oil Feed Pipe Fitting
NOTE:
Discard fitting, they are not reusable. |
| 2 | Turbocharger Oil Feed Pipe Bolt |
| 3 | Turbocharger Oil Feed Pipe Gaskets
NOTE:
Discard gaskets, they are not reusable. |
| 4 | Turbocharger Oil Feed Pipe Procedure Refer to Turbocharger Cleaning and Inspection |
