Floor Console and Overhead Lamps

WARNING: This page is about a different car, the 2016 Cadillac ATS. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Floor Console and Overhead Lamps
GM4050538Courtesy of GENERAL MOTORS COMPANY
