Hazard Warning Switch Replacement

Fig 1: Hazard Warning Switch
GM2888400Courtesy of GENERAL MOTORS COMPANY
Hazard Warning Switch Replacement

Callout Component Name
Preliminary Procedure
Remove the instrument panel accessory trim plate. Refer to Instrument Panel Accessory Trim Plate Replacement (Acadia) , Instrument Panel Accessory Trim Plate Replacement (Enclave) and Instrument Panel Accessory Trim Plate Replacement (Traverse) .
1 Hazard Warning Switch Fastener (Qty: 2)
CAUTION: Refer to Fastener Caution .
2 Hazard Warning Switch

Procedure

  1. Disconnect the electrical connector.
  2. After replacing the hazard warning switch, remove the instrument panel cluster fuse for a few seconds and then install the fuse.
