Fluid Diagrams

Park - Engine Running





Overdrive Range, First Gear





Overdrive Range, Second Gear





Overdrive Range, Third Gear





Overdrive Range, Fourth Gear - TCC Applied





Overdrive Range, 4-3 Downshift





Reverse





Neutral - Engine Running





Overdrive Range, 3-2 Downshift





Manual Third Gear





Manual Second Gear





Manual First Gear
