Valve Lifter Replacement - Right Side



Valve Lifter Replacement - Right Side

Removal Procedure

1. Remove the applicable camshaft(s).
2. Remove the rocker arms.




3. Remove the lifters.
4. Clean and inspect the camshaft(s) and the rocker arm(s). Repair or replace as necessary.

Installation Procedure




1. Install the lifters.
2. Install the rocker arms.
3. Install the applicable camshaft(s).
