Front Center Seat Riser Replacement (AE7)
WARNING: This page is about a different car, the 2008 GMC Sierra, 2008 GMC Cab & Chassis Sierra, 2008 Chevrolet Silverado, and 2008 Chevrolet Cab & Chassis Silverado. However, it is still accessible from the selected car via links, so may be relevant.
| Callout | Component Name |
|---|---|
|
CAUTION:
Do not strike or jolt the inflatable restraint front end sensor. Before applying power to the front end sensor make sure that it is securely fastened. Failure to observe the correct installation procedure could cause SIR deployment, personal injury, or unnecessary SIR system repairs. Preliminary Procedure: Remove the front center seat. Refer to Front Center Seat Replacement . |
|
| 1 | Front Center Seat Storage Compartment Bolt
NOTE:
Refer to Fastener Notice
.
Tighten: 9 N.m (80 lb in) |
| 2 | Front Center Seat Back Cushion Finish Cover |
| 3 | Front Center Seat Storage Compartment Bolt Tighten: 9 N.m (80 lb in) |
| 4 | Front Center Seat Back Cushion Latch Lower Cover |
| 5 | Front Center Seat Back Cushion Latch Upper Cover Tip: Slide the upper cover out of the lower cover. |
| 6 | Front Center Seat Armrest Bolt (Qty: 2) Tighten: 9 N.m (80 lb in) |
| 7 | Front Center Seat Armrest |
| 8 | Front Center Seat Armrest Bolt (Qty: 2) Tighten: 9 N.m (80 lb in) |
| 9 | Front Center Seat Back Cushion Latch |
| 10 | Front Center Seat Cushion |
| 11 | Front Center Seat Riser |
