Sunroof Air Deflector Replacement (Crew Cab)

WARNING: This page is about a different car, the 2007 GMC Sierra and 2007 Chevrolet Silverado. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: View Of Sunroof Air Deflector (Crew Cab)

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
1	Sunroof Air Deflector (Qty: 4) CAUTION: Refer to Glass and Sheet Metal Handling Caution . Procedure Open the sunroof to expose the 2 rivets located on each side. Tape off the under side of the sunroof track when drilling to prevent debris from entering the track. Drill out the rivets.
2	Sunroof Air Deflector Procedure: Before cycling the sunroof, vacuum out the sunroof track to remove all debris.

Callout

Component Name

Preliminary Procedure:
Remove the garnish molding. Refer to Sunroof Panel/Window Garnish Molding Replacement (Crew Cab) .

Sunroof Air Deflector (Qty: 4)

CAUTION: Refer to Glass and Sheet Metal Handling Caution .

Procedure

Open the sunroof to expose the 2 rivets located on each side.
Tape off the under side of the sunroof track when drilling to prevent debris from entering the track.
Drill out the rivets.

Sunroof Air Deflector
Procedure:
Before cycling the sunroof, vacuum out the sunroof track to remove all debris.
