Removal Procedure

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2003 GMC Savana Special, 2003 GMC Savana Camper Special, 2003 GMC Savana, 2003 Chevrolet RV Cutaway, and 2003 Chevrolet Cutaway. However, it is still accessible from the selected car via links, so may be relevant.
WARNING: Refer to HOOD HOLD-OPEN DEVICE CAUTION .
  1. Raise and support the hood.
  2. Remove the bolt (1) retaining the hood support rod (2) to the vehicle.
  3. Remove the support rod (2) from the vehicle.
    Fig 1: Removing Hood Support Rod
    G02422933Courtesy of GENERAL MOTORS CORP.
