Mirrors - Temperature Displays SC or OC
WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2003 GMC Savana Special, 2003 GMC Savana Camper Special, 2003 GMC Savana, 2003 Chevrolet RV Cutaway, and 2003 Chevrolet Cutaway. However, it is still accessible from the selected car via links, so may be relevant.
The following table will be used to measure the resistance of the sensor and compare it with the actual ambient temperature. The mirror's temperature accuracy should be within 5° of the actual temperature. The actual temperature should not be taken from a radio station, a sign displaying the temperature, etc.
A temperature measuring tool such as a thermometer should be used. Some temperature measuring tools may be within 5° of the actual temperature. Make sure to consult the manufacturer for the accuracy of the tool. This comparison can make the mirror seem off by 5° to 10° of the actual temperature when it is not.
Ambient Air Temperature Sensor Resistance
| °C | °F | Minimum Resistance K Ohms | Maximum Resistance K Ohms |
|---|---|---|---|
| -35 | -31 | 234.81 | 250.59 |
| -30 | -22 | 171.69 | 182.31 |
| -25 | -13 | 126.82 | 133.99 |
| -20 | -4 | 94.63 | 99.49 |
| -15 | 5 | 71.30 | 74.58 |
| -10 | 14 | 54.21 | 56.43 |
| -5 | 23 | 41.48 | 43.17 |
| 0 | 32 | 32.00 | 33.31 |
| 5 | 41 | 24.96 | 25.83 |
| 10 | 50 | 19.61 | 20.19 |
| 15 | 59 | 15.49 | 15.94 |
| 20 | 68 | 12.31 | 12.67 |
| 25 | 77 | 9.85 | 10.12 |
| 30 | 86 | 7.96 | 8.15 |
| 35 | 95 | 6.45 | 6.61 |
| 40 | 104 | 5.27 | 5.39 |
| 45 | 113 | 4.32 | 4.42 |
| 50 | 122 | 3.56 | 3.64 |
| 55 | 131 | 2.95 | 3.02 |
| 60 | 140 | 2.46 | 2.52 |
