Installation Procedure

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2003 GMC Savana Special, 2003 GMC Savana Camper Special, 2003 GMC Savana, 2003 Chevrolet RV Cutaway, and 2003 Chevrolet Cutaway. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the air outlet duct to the vehicle.
  2. Connect the air outlet duct to the floor vent.
  3. Install the retainers to the air outlet duct.
  4. Install the left rear quarter trim panel. Refer to Trim Panel Replacement - Left Body Side in Interior Trim .
    Fig 1: Installing Lower Auxiliary Air Outlet Duct
    G01217012Courtesy of GENERAL MOTORS CORP.
