Oil Filter Adapter and Oil Cooler Assembly Removal

WARNING: This page is about a different car, the 2010 GMC Sierra, 2010 GMC Cab & Chassis Sierra, 2010 Chevrolet Silverado, and 2010 Chevrolet Cab & Chassis Silverado. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: View Of Engine Coolant Pipe
    GM1336117Courtesy of GENERAL MOTORS CORP.
  1. Remove the engine coolant pipe.
  2. Remove the engine coolant pipe O-ring and discard.
    3. Fig 2: View Of Oil Filter Adapter/Oil Cooler
    GM1336118Courtesy of GENERAL MOTORS CORP.
  3. Remove the five oil filter adapter and oil cooler assembly bolts.
  4. Remove the oil filter adapter and oil cooler assembly.
