Coolant Air Bleed Pipe Removal

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2003 GMC Savana Special, 2003 GMC Savana Camper Special, 2003 GMC Savana, 2003 Chevrolet RV Cutaway, and 2003 Chevrolet Cutaway. However, it is still accessible from the selected car via links, so may be relevant.

Remove the engine coolant air bleed pipe bolts (1).
Remove the pipe (2) and gaskets (3).

Fig 1: Removing Engine Coolant Air Bleed Pipe Bolts, Pipe & Gaskets
Courtesy of GENERAL MOTORS CORP.
Remove the engine coolant air bleed pipe cover bolts (1) and covers (2).

Fig 2: Removing Engine Coolant Air Bleed Pipe Cover Bolts & Covers
Courtesy of GENERAL MOTORS CORP.
Remove the gaskets from the pipe and covers.
Discard the gaskets.

Fig 3: Removing Gaskets From Pipe & Covers
Courtesy of GENERAL MOTORS CORP.
Remove the hose (1) from the pipe (2).

Fig 4: Removing Hose From Pipe
Courtesy of GENERAL MOTORS CORP.
