Test Description

The numbers below refer to the step numbers on the diagnostic table.

  1. 2. Determines of DTCs C0300 or C0305 have set.
  2. 3. Helps determine if the DTC set due to a mechanical or an electrical fault.
  3. 4. Tests the integrity of the Motor Control circuit.
  4. 5. Determines whether the transfer case clutch pack is holding.
Fig 1: DTC C0374
G01643206Courtesy of GENERAL MOTORS CORP.
