Removal Procedure

WARNING: This page is about a different car, the 2003 GMC Sonoma, 2003 GMC Jimmy, 2003 Chevrolet S10 Pickup, and 2003 Chevrolet Blazer. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the bottom anchor bolt on the seat belt.
  2. Remove the trim cover of the shoulder belt opening.
  3. Using the J 38778  , remove the trim panel retainers from the rear side door.
  4. Feed the seat belt through the trim panel.
    Fig 1: Removing Trim Cover Of Shoulder Belt Opening
    G01477695Courtesy of GENERAL MOTORS CORP.
