Removal Procedure

WARNING: This page is about a different car, the 2002 GMC Safari and 2002 Chevrolet Astro. However, it is still accessible from the selected car via links, so may be relevant.
  1. Raise and support the vehicle.
  2. Disconnect the hydraulic brake booster inlet hose a from the of the power steering pump.
    3. Fig 1: Identifying Hydraulic Brake Booster Inlet Hose At Power Steering Pump
    G02501232Courtesy of GENERAL MOTORS CORP.
  3. Lower the vehicle.
  4. Disconnect the hydraulic brake booster inlet hose from the hydraulic brake booster.
    5. Fig 2: Identifying Hydraulic Brake Booster Inlet Hose At Hydraulic Brake Booster
    G02501233Courtesy of GENERAL MOTORS CORP.
  5. Remove the hydraulic brake booster inlet hose from vehicle.
