Starter Solenoid Clicks, Engine Does Not Crank

WARNING: This page is about a different car, the 2002 GMC Safari and 2002 Chevrolet Astro. However, it is still accessible from the selected car via links, so may be relevant.

Refer to illustration for STARTER SOLENOID CLICKS, ENGINE DOES NOT CRANK symptom test. See Fig 1 .

Fig 1: Starter Solenoid Clicks, Engine Does Not Crank Symptom Test
G00355887Courtesy of GENERAL MOTORS CORP.
