Fluid Pipes Installation
WARNING: This page is about a different car, the 2007 Saturn Vue. However, it is still accessible from the selected car via links, so may be relevant.
Courtesy of GENERAL MOTORS CORP.
- Install a 8 x 57.5 mm 3rd clutch apply fluid pipe (140) into the torque converter housing.
- Install a 10 x 153 mm transmission fluid cooler pipe (141) into the torque converter housing.
