Special Tools

WARNING: This page is about a different car, the 2007 Saturn Vue. However, it is still accessible from the selected car via links, so may be relevant.

Special Tools

Illustration	Tool Number/Description
Courtesy of GENERAL MOTORS CORP.	EN 46330 Timing Belt Tensioner Retaining Pin
Courtesy of GENERAL MOTORS CORP.	EN 46331 Timing Belt Tensioner Pulley Retaining Bolt
Courtesy of GENERAL MOTORS CORP.	EN 46333 Oil Pressure Testing Adapter
Courtesy of GENERAL MOTORS CORP.	EN 46334 Camshaft Oil Seal Driver
Courtesy of GENERAL MOTORS CORP.	EN 46335 Valve Spring Compressor - Head On-Vehicle
Courtesy of GENERAL MOTORS CORP.	EN 46336 Valve Guide Seal Installer
Courtesy of GENERAL MOTORS CORP.	EN 46337 Camshaft Sprocket/Crankshaft Balancer Holder
Courtesy of GENERAL MOTORS CORP.	EN 46339 Intake Rocker Arm Testing Adapter
Courtesy of GENERAL MOTORS CORP.	EN 46340 Intake Rocker Arm Testing Air Stopper
Courtesy of GENERAL MOTORS CORP.	EN 46341 Valve Guide Driver
Courtesy of GENERAL MOTORS CORP.	EN 46342 Driver Handle
Courtesy of GENERAL MOTORS CORP.	EN 46345 Valve Guide Reamer
Courtesy of GENERAL MOTORS CORP.	EN 46347 Crankshaft Front Oil Seal Driver
Courtesy of GENERAL MOTORS CORP.	EN 46348 Intake Rocker Arm Testing Air Pressure Regulator and Hose
Courtesy of GENERAL MOTORS CORP.	EN 46351 Crankshaft Rear Oil Seal Driver
Courtesy of GENERAL MOTORS CORP.	EN 46352 Intake Rocker Arm Testing Air Adapter
Courtesy of GENERAL MOTORS CORP.	EN 46353 Valve Spring Compressor Attachment - Head Off-Vehicle
Courtesy of GENERAL MOTORS CORP.	J 7872 Magnetic Base Dial Indicator
Courtesy of GENERAL MOTORS CORP.	J 8037 Ring Compressor
Courtesy of GENERAL MOTORS CORP.	J 24270 Cylinder Bore Ridge Reamer
Courtesy of GENERAL MOTORS CORP.	J 25070 Heat Gun - 500-750 F
Courtesy of GENERAL MOTORS CORP.	J 28410 Gasket Remover
Courtesy of GENERAL MOTORS CORP.	J 35268-A Camshaft/Front Main Seal Installer
Courtesy of GENERAL MOTORS CORP.	J 41742 Connecting Rod Guide Pin
Courtesy of GENERAL MOTORS CORP.	J 42065 Crank Hub Holding Tool
Courtesy of GENERAL MOTORS CORP.	J 42098 Crank Hub TORX® Socket
Courtesy of GENERAL MOTORS CORP.	J 43059 Valve Retainer Remover/Installer
Courtesy of GENERAL MOTORS CORP.	J 45059 Angle Meter
Courtesy of GENERAL MOTORS CORP.	J 45299 Engine Preluber
Courtesy of GENERAL MOTORS CORP.	SA9102E-A Valve Seal Remover/Replacer
Courtesy of GENERAL MOTORS CORP.	SA9105E Engine Support Fixture - 3-Bar
Courtesy of GENERAL MOTORS CORP.	SA9124E Regulator Valve Remover/Replacer
Courtesy of GENERAL MOTORS CORP.	SA9127E Gage Bar Set
Courtesy of GENERAL MOTORS CORP.	SA9140E Torque Angle Gage
Courtesy of GENERAL MOTORS CORP.	SA9178NE-A Dial Bore Gage
Courtesy of GENERAL MOTORS CORP.	SA9179NE Dial Indicator
Courtesy of GENERAL MOTORS CORP.	SA9187NE Cylinder Ridge Reamer
