Removal Procedure

WARNING: This page is about a different car, the 2002 GMC Safari and 2002 Chevrolet Astro. However, it is still accessible from the selected car via links, so may be relevant.
  1. Roll the window down.
  2. Remove the trim panel. Refer to TRIM PANEL REPLACEMENT - DOOR  .
  3. Remove the outer sealing strip from the door frame.
    4. Fig 1: Removing & Installing Outer Belt Sealing Strip
    G02506798Courtesy of GENERAL MOTORS CORP.
