Installation Procedure

WARNING: This page is about a different car, the 2003 GMC Sierra, 2003 GMC Cab & Chassis Sierra, 2003 Chevrolet Silverado, and 2003 Chevrolet Cab & Chassis Silverado. However, it is still accessible from the selected car via links, so may be relevant.
NOTE: Refer to FASTENER NOTICE .
  1. Install a new oil pan cover gasket (3), the cover (2) and bolts (1).

    Tighten

    Tighten the bolts to 12 N.m (106 lb in).

  2. Refill the engine oil.
    Fig 1: Installing Oil Pan Cover, Gasket & Bolts
    G02106740Courtesy of GENERAL MOTORS CORP.
