Diagnostic Aids
WARNING: This page is about a different car, the 2003 GMC Sierra, 2003 GMC Cab & Chassis Sierra, 2003 Chevrolet Silverado, and 2003 Chevrolet Cab & Chassis Silverado. However, it is still accessible from the selected car via links, so may be relevant.
Separate the EBCM from the BPMV in order to inspect for corrosion or any other condition that may cause a poor connection at the pump motor connector. Refer to Electronic Brake Control Module (EBCM) Replacement and TESTING FOR INTERMITTENT AND POOR CONNECTIONS .
If severe corrosion or other damage exists, the BPMV or the EBCM may need to be replaced.
