Audible Warnings Schematics

WARNING: This page is about a different car, the 2004 Chevrolet Corvette. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Audible Warnings Schematic
GM713222Courtesy of GENERAL MOTORS CORP.
