Installation Procedure

WARNING: This page is about a different car, the 2002 GMC Safari and 2002 Chevrolet Astro. However, it is still accessible from the selected car via links, so may be relevant.
NOTE: Refer to FASTENER NOTICE in GM Vehicles Cautions & Notices.
  1. Install the strut ball to lid or body by turning clockwise into the weldnut. Tighten:  Tighten the strut ball to 25 N.m (18 lb ft).
  2. Install the strut. Refer to STRUT REPLACEMENT - LIFT GATE  .
  3. Install the support. Close liftgate.
    4. Fig 1: Removing & Installing Lift Gate Strut Ball Stud
    G02507114Courtesy of GENERAL MOTORS CORP.
