Removal Procedure

WARNING: This page is about a different car, the 2002 GMC Safari and 2002 Chevrolet Astro. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the screws (1).
  2. Remove the striker assembly (2).
    3. Fig 1: Removing & Installing Lift Gate Lock Striker
    G02507167Courtesy of GENERAL MOTORS CORP.
