Removal Procedure

WARNING: This page is about a different car, the 2002 GMC Safari and 2002 Chevrolet Astro. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the trim panel. Refer to TRIM PANEL REPLACEMENT - REAR DOOR (CARGO DOORS)  or TRIM PANEL REPLACEMENT - REAR DOOR (E54)  .
  2. Use a soft-faced scraper, if needed, in order to peel the water deflector away from the door. Refer to Water Deflector Replacement  .
  3. Remove the control rod from the outside handle.
  4. Remove the outside handle nuts.
  5. Remove the outside handle.
    6. Fig 1: Removing & Installing Rear Door Outside Handle
    G02507123Courtesy of GENERAL MOTORS CORP.
