Section 1212 (Suspension System General Diagnosis)
>>
Diagnostic Information and Procedures
>>
Ball Joint Inspection
Ball Joint Inspection
WARNING:
This page is about a different car, the 2003 Pontiac Grand Prix. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Ball Joint Inspection (Steps 1 - 5)
Courtesy of GENERAL MOTORS CORP.
Fig 2: Ball Joint Inspection (Steps 6 - 7)
Courtesy of GENERAL MOTORS CORP.
