Installation Procedure

WARNING: This page is about a different car, the 2003 Chevrolet Corvette. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the exhaust pipe hanger.
    NOTE: Refer to FASTENER NOTICE in Cautions and Notices.
  2. Install the upper exhaust pipe hanger bolts.

    Tighten

    Tighten the exhaust pipe hanger bolts to 50 N.m (37 lb ft).

  3. Install the catalytic converter. Refer to CATALYTIC CONVERTER REPLACEMENT .
    Fig 1: Upper Exhaust Pipe Hanger Bolts
    G01971229Courtesy of GENERAL MOTORS CORP.
