Home >> GMC >> 2003 >> Safari Van Cargo, AWD >> Repair and Diagnosis >> Electrical >> Motors, Switches, Relays >> Battery >> Diagnostic Information and Procedure >> DTC P0563 >> Diagnostic Test

Diagnostic Test

Fig 1: DTC P0563 Diagnostic Table
G01646471Courtesy of GENERAL MOTORS CORP.
