Installation Procedure

  1. Install the power seat switch to the trim plate by snapping the switch into place.
  2. Connect the power seat switch electrical connector.
    NOTE: Refer to Fastener Notice in Cautions and Notices.
  3. Install the screws that retain the power seat trim plate to the cover.

    Tighten

    Tighten the screws that retain the power seat trim plate to the cover to 2 N.m (18 lb in).

  4. Install the seat bolts to the seat riser.

    Tighten

    Tighten the riser to seat retaining bolts to 30 N.m (22 lb ft).

  5. Install the seat riser trim cover.
  6. Install the screws to seat riser trim cover.

    Tighten

    Tighten the screws to seat riser trim cover to 2 N.m (18 lb in).

    Fig 1: Installing Screws Retaining Power Seat Trim Plate To Cover
    G01567113Courtesy of GENERAL MOTORS CORP.
