Installation Procedure

NOTE: Refer to FASTENER NOTICE in Cautions and Notices.

Install the liftgate striker (2) with the screws (1).

Tighten

Tighten the liftgate striker screws to 10 N.m (88 lb in).

Fig 1: Installing Lift Gate Lock Striker
G01567391Courtesy of GENERAL MOTORS CORP.
