Installation Procedure

  1. Push the support rod retainer into place.
  2. Insert the retainer tab into the slot in order to install the support rod to the vehicle.
    NOTE: Refer to Fastener Notice in Cautions and Notices.
  3. Install the support rod-to-radiator support bolt.

    Tighten

    Tighten the support rod to radiator support bolts to 15 N.m (11 lb ft).

  4. Lower the hood.
    Fig 1: Installing Hood Support Rod
    G01566844Courtesy of GENERAL MOTORS CORP.
