Blower Motor Resistor Replacement - A/C Auxiliary

REMOVAL PROCEDURE




1. Remove the left body side trim panel.
2. Remove the electrical connector.
3. Remove the screws that retain the resistor (4) to the case.
4. Remove the auxiliary A/C blower motor resistor assembly from the case.

INSTALLATION PROCEDURE




1. Install the auxiliary A/C blower motor resistor assembly into the case.

NOTE: Refer to Fastener Notice in Caution and Notices.

2. Install the screws that retain the resistor to the case.

Tighten
Tighten the screws that retain the resistor to the case to 2 N.m (18 lb in).

3. Install the electrical connector.
4. Install the left body side rear trim panel.
