Rear Door Weatherstrip Replacement (E54)

Rear Door Weatherstrip Replacement (E54)

Tools Required

J 38778 Door Trim Pad and Garnish Clip Remover

Removal Procedure

1. Use the J 38778 in order to remove the retainers.
2. Use 3M Release Agent in order to break the weatherstrip adhesive bond.
3. Use the J 38778 in order to remove the plastic retainers.




4. Remove the left door weatherstrip.




5. Remove the right door weatherstrip.

Installation Procedure




1. Use 3M Weatherstrip adhesive or an equivalent in order to install the right door weatherstrip.




2. Use 3M Weatherstrip adhesive or an equivalent in order to install the left door weatherstrip.
3. Install the plastic retainers into place. Push the retainers into place until the retainers are fully seated.
