Diagnostic System Check - HVAC Systems - Manual
Diagnostic System Check - HVAC Systems - Manual
WARNING:
This page is about a different car, the 2003 Pontiac Aztek and 2003 Buick Rendezvous. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Diagnostic Manual HVAC Systems Specification Chart
Courtesy of GENERAL MOTORS CORP.
