Diagnostic Aids

A poor connection can cause an intermittent Code 39. Using a digital volt-ohmmeter connected to the circuit, move the related wiring and connectors. An intermittent condition would cause a voltage reading change.

Fig 1: Code 39, TCC Circuit Diagram (3.3L W/3T40 Transaxle)
G91B07337Courtesy of GENERAL MOTORS CORP.
