Diagnostic Aids
If the engine is allowed to cool overnight, the coolant and MAT sensors should read close to each other, when measured with a Scan tester. A Code 25 will also result if signal and ground circuits become open. Refer to TEMPERATURE-TO-RESISTANCE VALUES table.
