Front Cover Oil Seal: Installation
WARNING: This page is about a different car, the 1995 Plymouth Voyager, 1995 Plymouth Grand Voyager, 1995 Dodge Grand Caravan, and 1995 Dodge Caravan. However, it is still accessible from the selected car via links, so may be relevant.
- Install front cover oil seal on crankshaft with spring side of oil seal toward the engine. Using Oil Seal Installer (C-4992), install front cover oil seal until oil seal is even with surface of timing chain cover.
- Using Plate (L-4524), thrust bearing/washer and bolt, install vibration damper. Remove plate, thrust bearing/washer and bolt. Install and tighten vibration damper bolt to specification. See TORQUE SPECIFICATIONS . To install remaining components, reverse removal procedure.
