GMC
>>
1986
>>
Safari Van M V6-262 4.3L
>>
Repair and Diagnosis
>>
Engine, Cooling and Exhaust
>>
Engine
>>
Locations
>>
Temperature Transducer
Temperature Transducer
Left Side Engine Wiring Harness.:
LH Side Of Engine Wiring Harness
Applicable to: 1986 Astro Van & Safari w/4-151/2.5L Engine
